Product Description:
The SMC CQ2 Series seal kits are authentic replacement components specifically engineered for the maintenance and refurbishment of CQ2A, CDQ2A, CQ2B, and CDQ2B series compact pneumatic cylinders. These kits ensure the cylinders continue to operate effectively by providing all essential sealing parts.
Each seal kit includes a comprehensive set of vital sealing elements, such as the piston seal, rod seal, and tube gasket. These components are crafted from premium NBR (nitrile rubber), guaranteeing dependable performance and an extended service lifespan under various operating conditions.
Available for bore sizes ranging from 12mm up to 100mm, the seal kits are ordered according to the specific bore diameter of the cylinder in need of repair. By replacing worn seals, these kits help restore the cylinder’s sealing efficiency, prevent air leakage, and maintain optimal force output as well as quick response times.
Designed to be compatible with both the standard CQ2 series compact cylinders and the anti-lateral load variants, these seal kits offer a cost-effective solution. Rather than purchasing a new cylinder assembly, users can prolong the life of their existing cylinders by installing these high-quality seal kits.
Features:
Complete Seal Kit for Cylinder Overhaul
This complete seal kit comprises a piston seal, a rod seal, and a tube gasket, providing everything needed for a comprehensive cylinder overhaul. It ensures that your cylinder operates efficiently by replacing all critical sealing components at once.
Authentic SMC Quality
Each seal kit is manufactured strictly according to SMC’s precise specifications. This guarantees a perfect fit and dependable sealing performance, maintaining the high standards expected from genuine SMC parts.
Durable NBR Seal Material
The seals are made from premium nitrile rubber (NBR), known for its outstanding resistance to wear and compression set. Additionally, these seals withstand industrial air media effectively, ensuring long-lasting functionality.
Extensive Bore Size Options
Available in a wide range of bore sizes, this seal kit caters to dimensions of 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, and 100mm, covering most common cylinder sizes.
Compatibility with Multiple Cylinder Models
This kit is compatible with various cylinders in the CQ2 family, including CQ2A, CDQ2A, CQ2B, CDQ2B, CQ2Z, and CQP2 models, making it a versatile choice for maintenance needs.
Restores Cylinder Performance
By replacing worn seals, the kit helps restore the cylinder’s original force, speed, and cushioning capabilities, ensuring smooth and efficient operation.
Minimizes Downtime
The easy and rapid seal replacement process reduces production downtime, preventing costly interruptions and avoiding the need to replace the entire cylinder.
Cost-Effective Maintenance Solution
Providing performance equivalent to a new cylinder at a fraction of the cost, this seal kit is an economical option for ongoing maintenance and repairs.
Environmentally Compliant
Fully RoHS compliant, the seal kit adheres to environmental and safety standards, making it suitable for responsible industrial use.
Wide Operating Temperature Range
Designed to perform reliably across temperatures from -10°C to +70°C, these seals support your operations in various environmental conditions.
Technical Parameters:
| Product Type |
Cylinder Seal Kit / Repair Kit |
| Operating Temperature |
-10°C To +70°C |
| Kit Contents |
Piston Seal, Rod Seal, Tube Gasket |
| Bore Sizes Available |
12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm |
| Seal Material |
NBR |
| Series |
CQ2 |
| Compatible Cylinder Series |
CQ2A, CDQ2A, CQ2B, CDQ2B, CQ2Z, CQP2, CQ2□S |
| Brand |
SMC |
Applications:
In the field of factory automation, maintaining compact pneumatic cylinders is essential for the smooth operation of automated production lines. Regular upkeep ensures that these components function efficiently, minimizing downtime and enhancing productivity.
When it comes to material handling, repairing cylinders used in conveyors, pick-and-place units, and various handling systems is critical. Proper maintenance helps in sustaining the reliability and accuracy of these systems, which are vital for seamless material flow.
Packaging machinery also relies heavily on pneumatic cylinders. Replacing seals in cylinders within packaging and filling equipment helps prevent leaks and ensures consistent performance, thereby maintaining the integrity of packaging processes.
In the domain of electronic component manufacturing, the maintenance of cylinders integrated into precision assembly equipment is crucial. This upkeep supports the high precision and delicate operations required in assembling electronic parts.
The automotive assembly sector depends on the repair of compact cylinders found in assembly tools and testing fixtures. Keeping these components in optimal condition contributes to efficient vehicle assembly and quality assurance processes.
For food and beverage processing, cylinder maintenance is necessary within both processing and packaging lines. Ensuring the proper function of pneumatic cylinders helps maintain hygiene standards and operational efficiency in these sensitive applications.
More broadly, in any pneumatic application, reliable sealing and performance restoration of compact cylinders is paramount. Effective maintenance practices guarantee long-lasting functionality across diverse industrial uses.
