Product Description:
These cylinder seal kits are meticulously engineered replacement sets tailored for the maintenance and comprehensive overhaul of RHC series high power pneumatic cylinders. Suitable for bore diameters ranging from 20mm to 100mm, each kit contains all the crucial sealing components necessary to perform a complete cylinder rebuild. The components include a cushion seal, piston seal, wear ring, cylinder tube gasket, rod seal, and various O-rings.
Crafted from premium materials such as NBR (nitrile rubber), specialized resin, and urethane, the seals offer exceptional durability and reliable performance for a broad spectrum of industrial pneumatic uses. The RHC series cylinders are specifically engineered to handle high-speed and heavy-load conditions. They feature an extended cushion design that effectively absorbs impacts from heavy or rapid movements while preserving the straightforwardness found in standard air cushion cylinders. Additionally, each kit comes with a 10-gram grease pack to ensure proper lubrication during the installation process.
Using these seal kits for regular seal replacement helps in restoring the original performance of the cylinders, preventing air leaks, and considerably extending the lifespan of your existing actuators. This maintenance approach is cost-effective, providing significant savings compared to purchasing entirely new cylinders. The kits are fully compatible with both the RHCL and RHCB models within the high power cylinder range.
Note: Item 21, the piston gasket, is a non-replaceable component and is therefore not included in the seal kit.
Features:
Complete Seal Kit
This comprehensive kit contains everything needed for a full cylinder rebuild. Included are the cushion seal, piston seal, wear ring, cylinder tube gasket, rod seal, and multiple O-rings to ensure a complete replacement set.
Wide Bore Size Availability
The seal kits come in a broad range of bore sizes to fit various cylinders. Sizes available include 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, and 100mm, accommodating most standard cylinder requirements.
High-Quality Materials
Constructed from premium NBR (nitrile rubber), special resin, and urethane, these seals provide excellent resistance against wear, compression set, and exposure to typical pneumatic media, ensuring durability and reliability.
Designed for High Power Applications
This kit is compatible with RHC series cylinders, which boast energy absorption capacities 10 to 20 times greater than general-purpose cylinders, making them suitable for demanding operational environments.
Includes Grease Pack for Proper Lubrication
Each kit comes with a 10-gram grease pack, facilitating correct lubrication during assembly to enhance seal performance and longevity.
Restores Cylinder Performance
Replacing worn seals effectively eliminates internal and external leaks, restoring the cylinder’s original force output and speed, thereby improving overall performance.
Supports High-Speed Operation
These kits are suitable for cylinders that operate at speeds up to 3000 mm/s under light to medium load conditions, ensuring reliable sealing even in fast-moving applications.
Cost-Effective Maintenance Solution
Offering a significant cost saving compared to purchasing new cylinders, these seal kits extend the service life of actuators and reduce maintenance expenses.
Simple and Quick Installation
Designed for easy replacement, the kits can be installed using standard tools, minimizing downtime and simplifying maintenance procedures.
Wide Operating Temperature Range
Suitable for use in environments ranging from -10°C to +70°C, these seals maintain performance across a broad temperature spectrum.
Ideal for Inventory Management
With a single kit number assigned per bore size, managing stock becomes more straightforward, aiding efficient parts control and procurement.
Technical Parameters:
| Bore Sizes |
20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, 100mm |
| Series |
RHC / RHCL / RHCB |
| Product Type |
Seal Kit / Repair Kit |
| Kit Contents |
Cushion Seal, Piston Seal, Wear Ring, Tube Gasket, Rod Seal, O-rings |
| Operating Temperature |
-10°C To +70°C |
| Seal Materials |
NBR |
| Keywords |
3/8‑2 1/2 inch solenoid valve diaphragm, Pneumatic solenoid valve membrane, ASCO series 210 diaphragm |
Applications:
High-Speed Automation
Maintenance of cylinders plays a crucial role in high-speed automated production lines. Ensuring these cylinders are functioning properly helps maintain efficiency and minimize downtime in fast-paced manufacturing environments.
Material Handling
Cylinders used in conveyors, pick-and-place units, and various material handling systems often require repair and upkeep. Proper maintenance ensures smooth operation and extends the lifespan of these critical components.
Clamping and Pressing
For applications involving high-force clamping, lifting, and pressing, seal replacement in cylinders is essential. Reliable seal performance supports the demanding conditions typical in these operations.
Packaging Machinery
Cylinder seal kits are specifically designed for use in high-speed packaging and filling equipment. Regular maintenance with appropriate seal kits is key to sustaining the performance of packaging machinery.
Electronic Component Manufacturing
In the field of precision assembly for electronic components, cylinder maintenance ensures accuracy and consistency. Well-maintained cylinders contribute to the overall quality of the manufacturing process.
General Industrial Pneumatics
Across a wide range of industrial pneumatic applications, reliable high-power cylinder sealing is fundamental. Proper sealing supports the operation of cylinders in various demanding environments.
