Product Description:
These guide rod cylinder seal kits are precisely engineered replacement sets specifically designed for the maintenance and comprehensive overhaul of CQMB series compact guided pneumatic cylinders. They are available in various bore sizes ranging from 12mm to 63mm. Each kit includes all the essential sealing components needed for a complete rebuild of the cylinder, such as a piston seal, rod seal, and tube gasket.
The seals are made from premium-quality NBR (nitrile rubber), which provides exceptional resistance against wear, oil, and abrasion. This ensures reliable and long-lasting performance in various pneumatic applications. The CQMB series compact guide cylinders incorporate an integrated guide rod and plate design, delivering high non-rotating accuracy of ±0.2° along with lateral load resistance that is four times greater than standard CQ2K cylinders. This makes them ideal for applications requiring precision assembly and pick-and-place operations.
By regularly replacing the seals with these kits, users can restore the cylinder's optimal performance, prevent air leakage, and significantly extend the lifespan of existing actuators. This maintenance solution is cost-effective compared to purchasing a full replacement cylinder. Please note that the seal kit does not include a grease pack, which must be ordered separately. The recommended grease pack has the part number GR-S-010 and comes in a 10g size.
Features:
Complete Seal Kit for Full Cylinder Rebuilds
Each seal kit is designed to include all necessary components for a complete cylinder overhaul. The kit comprises a piston seal, a rod seal, and a tube gasket, ensuring a comprehensive rebuild solution.
Wide Range of Bore Sizes
Our kits are available in a variety of bore sizes to suit different cylinders. Sizes include 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm, catering to a broad range of applications.
Durable High-Quality NBR Seals
The seals are made from nitrile rubber (NBR), known for its excellent resistance to oil and wear. This ensures long-lasting performance and reliability in demanding environments.
Compatibility with CQMB Series Cylinders
Specifically engineered for CQMB compact guide rod cylinders, these kits fit models that feature built-in guide rods, guaranteeing perfect integration and optimal performance.
Restore Your Cylinder's Original Performance
By replacing worn or damaged seals, the kit effectively eliminates air leakage. This restoration improves the cylinder’s original force and operational speed, enhancing overall efficiency.
Maintains Non-Rotating Precision
These seals support cylinders with a non-rotating accuracy of ±0.2°, ensuring precise operation without unwanted rotation during use.
Exceptional High Lateral Load Resistance
Suitable for use in cylinders that can withstand lateral loads up to four times greater than those of the CQ2K series, providing enhanced durability under demanding mechanical stress.
Cost-Effective Solution for Maintenance
This seal kit offers a budget-friendly alternative to purchasing a new cylinder. Using the kit extends the service life of actuators, making it an efficient maintenance option.
Wide Operating Temperature Range
Designed to function reliably in temperatures ranging from -10°C to +70°C, these seals are suitable for various industrial environments and conditions.
Simplified Inventory Management
With only one unique kit number assigned per bore size, stocking and inventory control are streamlined, reducing complexity for maintenance teams.
Optional Grease Pack for Installation
To ensure proper lubrication during installation, a separate grease pack (GR-S-010, 10g) is available. This grease aids in smooth seal placement and improves overall seal life.
Technical Parameters:
| Kit Contents |
Piston Seal, Rod Seal, Tube Gasket |
| Series |
CQMB |
| Operating Temperature Range |
-10°C To +70°C |
| Bore Sizes |
12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm |
| Product Type |
Seal Kit / Repair Kit |
| Seal Material |
NBR |
Applications:
Pick and Place Units
We offer specialized maintenance services for guided cylinders utilized in precision positioning systems, ensuring optimal performance and accuracy.
Factory Automation
Our team provides expert repair solutions for guided cylinders employed in automated production lines, minimizing downtime and enhancing productivity.
Material Handling
We handle seal replacements for cylinders used in conveyors and various handling systems to maintain smooth and reliable operations.
Clamping and Pressing
Maintenance services are available for cylinders involved in high-force clamping and pressing tasks, ensuring durability and consistent performance.
Packaging Machinery
Seal kits for cylinders used in packaging and filling machines are provided to maintain efficiency and prevent leaks.
Electronic Component Manufacturing
We support cylinder maintenance in precision assembly equipment commonly used in the production of electronic components.
CNC Machines
Our services include repair of guided cylinders in machine tools that demand high precision, vital for CNC machining applications.
General Industrial Pneumatics
For any industrial process requiring dependable guided cylinder sealing, we offer comprehensive maintenance and repair services.
Support and Services:
Our Pulse Valve Diaphragm product is designed to deliver reliable performance and long service life in various industrial applications. For technical support, we provide comprehensive assistance including installation guidance, troubleshooting, maintenance tips, and replacement procedures to ensure optimal operation of your pulse valve system.
We recommend regular inspection of the diaphragm for signs of wear, damage, or deformation to prevent operational issues. Proper cleaning and handling are essential to maintain the diaphragm’s integrity and functionality.
In case of performance degradation, our support team can help diagnose potential causes such as improper installation, material incompatibility, or environmental factors, and suggest corrective actions or suitable replacement parts.
Our services also include providing detailed product documentation, including specifications, installation manuals, and maintenance schedules to support your technical staff in effective product management.
For customized solutions or specific application requirements, we offer consultation services to tailor the pulse valve diaphragm to meet your operational needs, ensuring enhanced efficiency and durability.
Packing and Shipping:
Product Packaging and Shipping for Pulse Valve Diaphragm
The Pulse Valve Diaphragm is carefully packaged to ensure maximum protection during transit. Each diaphragm is individually wrapped in anti-static and moisture-resistant material to prevent damage from environmental factors. The wrapped diaphragms are then securely placed in sturdy, cushioned boxes to avoid any impact or deformation.
For bulk orders, the diaphragms are packed in well-organized layers within reinforced cartons, with sufficient padding between layers to maintain product integrity. All packaging materials comply with international shipping standards to guarantee safe delivery.
Shipping options include air freight, sea freight, and express courier services, selected based on customer requirements and destination. Each shipment is labeled clearly with product details, handling instructions, and tracking information to ensure smooth customs clearance and timely delivery.
We prioritize careful packaging and reliable shipping to deliver Pulse Valve Diaphragms that meet the highest quality standards and arrive in perfect condition.
