Product Description:
These air gripper seal kits are precisely engineered replacement sets specifically designed for the maintenance and overhaul of MHL2 series parallel style wide opening pneumatic grippers. They are available for bore sizes ranging from 10mm to 40mm. Each kit includes all the essential sealing components necessary for a comprehensive gripper rebuild, such as gaskets, piston seals, and rod seals.
Manufactured from high-quality NBR (nitrile rubber), the seals provide excellent resistance to wear, oil, and abrasion, ensuring dependable performance in pneumatic applications. The MHL2 series grippers incorporate a double piston mechanism, delivering high gripping force within a compact form factor. These grippers are well-suited to handle workpieces with significant dimensional variations.
Using these seal kits for regular replacements helps restore the gripper’s performance, prevents air leakage, and significantly extends the service life of the existing actuators. This maintenance option offers a cost-effective alternative compared to full actuator replacement.
Please note that the seal kit does not include a grease pack, which needs to be ordered separately. The recommended grease pack can be found under part number GR-S-010, containing 10 grams.
Features:
Complete Seal Kit for Full Gripper Rebuild
This comprehensive seal kit includes all necessary components such as gaskets, piston seals, and rod seals, designed to provide a full rebuild solution for your gripper.
The kit is available in multiple bore sizes including 10mm, 16mm, 20mm, 25mm, 32mm, and 40mm, ensuring compatibility with a wide range of pneumatic grippers.
Made from NBR (nitrile rubber), the seals exhibit excellent resistance to oil and wear, contributing to enhanced durability and reliable performance.
Specifically engineered for the MHL2 series parallel style wide opening pneumatic grippers, this seal kit restores optimal gripping force and sealing efficiency by effectively eliminating air leaks.
Providing a cost-effective alternative to replacing the entire gripper assembly, this kit helps extend the service life of your actuator while reducing maintenance expenses.
Installation is quick and straightforward, requiring only standard tools, allowing you to resume operations promptly.
The seal kit supports an operating temperature range from -10°C to +60°C, and its double-acting design ensures reliable gripping action in both directions.
Each bore size is assigned a unique kit number, simplifying inventory management and ordering processes.
Additionally, a separate grease pack (GR-S-010, 10g) is available to complement the seal kit and enhance maintenance procedures.
Technical Parameters:
| Series |
MHL2 |
| Operating Temperature |
-10°C To +60°C |
| Bore Sizes |
10mm, 16mm, 20mm, 25mm, 32mm, 40mm |
| Kit Contents |
Gasket, Piston Seal, Rod Seal |
| Seal Material |
NBR |
| Product Type |
Seal Kit / Repair Kit |
Applications:
Pick and Place Units
Maintenance services are provided for parallel grippers used in precision positioning systems. This ensures optimal performance and longevity of the equipment.
Factory Automation
We specialize in the repair of grippers utilized within automated production lines, helping to minimize downtime and maintain efficient manufacturing processes.
Material Handling
Seal replacement for grippers in conveyors and various handling systems is offered to enhance reliability and operational stability.
Packaging Machinery
Our team performs maintenance on grippers incorporated in packaging and filling equipment, ensuring consistent and accurate packaging operations.
Electronic Component Manufacturing
Repair services for grippers used in precision assembly equipment in the electronics industry are available to support high-quality production standards.
General Industrial Pneumatics
We cater to any application that requires dependable air gripper sealing, providing solutions that meet rigorous industrial demands.
Customization:
Introducing the SMC Pulse Valve Diaphragm, model number MHL2 10-PS, a premium seal kit designed for efficient and reliable operation. Manufactured in China and certified with CE, this pilot valve repair kit is tailored to meet the highest quality standards. It is compatible with various bore sizes including 10mm, 16mm, 20mm, 25mm, 32mm, and 40mm, making it versatile for different applications.
This seal kit, part of the MHL2 series, operates effectively within a temperature range of -10°C to +60°C. The kit contents include a gasket, piston seal, and rod seal, ensuring a complete repair solution for your solenoid valves. It is particularly suitable for use with ASCO series 210 diaphragm valves and 3/8‑2 1/2 inch solenoid valve diaphragms, providing excellent performance and durability.
The minimum order quantity is 1 piece, with a supply ability of 5000 pieces per month. Pricing is negotiable to meet your budget requirements. Orders are carefully packed in cartons to ensure safe delivery, with a delivery time of 1-7 work days after payment. Payment terms are flexible, accepting T/T, Western Union, and Paypal for your convenience.
Choose the SMC Pulse Valve Diaphragm MHL2 10-PS seal kit for a reliable, high-quality repair solution that enhances the performance and longevity of your solenoid valves.
Support and Services:
Our Pulse Valve Diaphragm is engineered for optimal performance and durability in various industrial applications. To ensure proper installation and maintenance, please refer to the detailed user manual provided with the product.
For technical support, we offer comprehensive troubleshooting guides and expert assistance to address any operational issues you may encounter. Our support team is equipped to help with diaphragm replacement, pulse valve calibration, and performance optimization.
We recommend regular inspection and timely replacement of the diaphragm to maintain system efficiency and prevent unexpected downtime. Genuine replacement parts are available to guarantee compatibility and longevity.
Additionally, we provide customized service solutions including on-site inspections, maintenance training, and system audits to help maximize the lifespan and reliability of your pulse valve systems.
For detailed service plans and further technical information, please consult our product documentation or visit our support portal.
