Product Description:
These compact guide cylinder seal kits are precisely engineered replacement sets specifically designed for the maintenance and overhaul of the MGQ series guided pneumatic cylinders. They are available for bore sizes ranging from 12mm to 63mm. Each kit contains all the essential sealing components needed for a complete cylinder rebuild, including piston packing, rod packing, gasket A, and gasket B.
The seals included in these kits are made from high-quality NBR (nitrile rubber), which provides excellent resistance to wear, oil, and abrasion. This ensures reliable performance in various pneumatic applications. The MGQ series compact guide cylinders feature an integrated guide design that offers lateral load resistance and maintains high non-rotating accuracy, making them ideal for use in stoppers, lifters, conveyor lines, and other precision automation systems.
The MGQ series is offered with two different bearing types to suit different application needs: the slide bearing (MGQM), which is designed for impact resistance, and the ball bushing bearing (MGQL), which ensures smooth operation and is suited for high-precision tasks. Depending on the bore size and bearing type, the non-rotating accuracy ranges from ±0.04° to ±0.08°. Additionally, all models come equipped with built-in magnets for automatic switch position detection throughout the entire stroke.
Regular replacement of seals using these kits helps restore the cylinder’s performance, prevents air leakage, and significantly extends the service life of existing actuators at a much lower cost than a full replacement. Please note that the seal kit does not include a grease pack, which must be ordered separately (grease pack part number: GR-S-010, 10g).
Features:
Complete Seal Kit for Cylinder Rebuild
This comprehensive seal kit contains everything needed for a full cylinder rebuild, including piston packing, rod packing, gasket A, and gasket B. It ensures that all essential components are replaced to restore optimal cylinder function.
Wide Range of Bore Sizes
The kit is available in multiple bore sizes to accommodate various cylinders, including 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm options, providing flexibility for different applications.
Durable High-Quality NBR Seals
Featuring nitrile rubber (NBR) seals, the kit offers excellent resistance to oil and wear, ensuring long-lasting performance and reliability under demanding conditions.
Compatibility with MGQ Series Cylinders
Specifically designed for MGQ compact guide rod cylinders that include an integrated guide, this kit guarantees proper fit and function for these specialized actuators.
Restores Cylinder Performance
Replacing worn seals with this kit eliminates air leakage, effectively restoring the cylinder’s original force and speed for improved operational efficiency.
Precision Non-Rotating Design
This seal kit is compatible with cylinders that offer a non-rotating accuracy ranging from ±0.04° to ±0.08°, maintaining high precision during operation.
Superior Lateral Load Resistance
The slide bearing design provides more than twice the lateral load strength compared to conventional stopper cylinders, enhancing durability and performance under side loads.
Built-In Magnet for Position Detection
All models include a built-in magnet that enables auto switch position detection, supporting efficient control and monitoring of cylinder position.
Cost-Effective Maintenance Solution
This kit offers a budget-friendly alternative to purchasing a new cylinder, extending the service life of your actuators and reducing overall maintenance expenses.
Suitable Operating Conditions
The seal kit is designed to operate effectively within a temperature range of -10°C to +60°C and a pressure range of 0.1 to 1.0 MPa, covering a wide array of standard application environments.
Inventory Simplification
With a single kit number assigned per bore size, inventory management is streamlined, making it easier to stock and reorder as needed.
Optional Grease Pack Available
For proper lubrication during installation, a separate grease pack (GR-S-010, 10g) is available, ensuring optimal seal performance and longevity.
Technical Parameters:
| Product Type |
Seal Kit / Repair Kit |
| Series |
MGQ |
| Operating Temperature Range |
-10°C To +60°C |
| Seal Material |
NBR (Nitrile Rubber) |
| Action Type |
Double Acting |
| Bore Sizes |
12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm |
| Kit Contents |
Piston Packing, Rod Packing, Gasket A, Gasket B |
| Proof Pressure |
1.5 MPa |
Applications:
Conveyor Line Stoppers
We provide maintenance services for compact guide cylinders that are utilized as stoppers and positioning devices within conveyor lines. Ensuring their reliable operation is crucial for smooth production processes.
Lifters and Pushers
Our expert seal replacement services cater to cylinders used in lifting and pushing applications. This maintenance helps maintain optimal performance and extends the lifespan of the equipment.
Pick and Place Units
We specialize in the repair of guided cylinders employed in precision positioning systems, such as pick and place units, to ensure accurate and consistent operation.
Factory Automation
Our maintenance solutions cover guided cylinders used in automated production lines, supporting efficient and uninterrupted factory automation processes.
Material Handling
We offer seal kits specifically designed for cylinders involved in conveyors and material handling systems, helping maintain their reliability and functionality.
Packaging Machinery
Our cylinder maintenance services extend to packaging and filling equipment, ensuring that machinery operates smoothly and meets production demands.
Electronic Component Manufacturing
We provide cylinder repair services tailored to precision assembly equipment used in electronic component manufacturing, enhancing accuracy and equipment durability.
General Industrial Pneumatics
Our expertise encompasses any application requiring dependable sealing of compact guide cylinders, guaranteeing consistent performance in diverse industrial pneumatic systems.
Customization:
Introducing the SMC MGQ12-PS Pulse Valve Diaphragm, a high-quality seal kit designed to meet your pneumatic system needs. Manufactured in China and CE certified, this product ensures reliable performance and durability.
Our Pulse Valve Diaphragm is compatible with a range of valves, including the 3/8‑2 1/2 inch solenoid valve diaphragm and ASCO series 210 diaphragm, making it an ideal replacement part for various pneumatic solenoid valve membranes.
The kit includes essential components such as piston packing, rod packing, Gasket A, and Gasket B, all made from durable NBR (Nitrile Rubber) seal material. It is engineered to withstand a proof pressure of 1.5 MPa and operates efficiently within a temperature range of -10°C to +60°C.
With a minimum order quantity of 1 piece and a supply ability of 5000 pieces per month, we offer flexible pricing through negotiation. Packaging is done securely in cartons to ensure safe delivery.
Delivery time is prompt, ranging from 1 to 7 work days after payment. We accept various payment terms including T/T, Western Union, and Paypal for your convenience.
Choose the SMC MGQ12-PS Pulse Valve Diaphragm for a reliable, high-performance solution in pneumatic solenoid valve membrane maintenance and repair.
