Product Description:
These compact guide cylinder seal kits are precision-engineered replacement sets specifically designed for the maintenance and overhaul of MGQ series guided pneumatic cylinders. They are available for bore sizes ranging from 12mm to 63mm. Each kit includes all the essential sealing components required for a complete cylinder rebuild, such as piston packing, rod packing, gasket A, and gasket B.
The seals are manufactured using high-quality NBR (nitrile rubber), which provides excellent resistance to wear, oil, and abrasion. This ensures reliable performance in various pneumatic applications. The MGQ series compact guide cylinders feature an integrated guide design that offers lateral load resistance and high non-rotating accuracy. This makes them particularly suitable for use as stoppers and lifters in conveyor lines and other precision automation systems.
The MGQ series is offered with two types of bearings: slide bearing (MGQM), which provides impact resistance, and ball bushing bearing (MGQL), which enables smooth operation and is ideal for high-precision applications. Depending on the bore size and bearing type, non-rotating accuracy ranges from ±0.04° to ±0.08°. Furthermore, all models come equipped with built-in magnets to facilitate auto switch position detection across the entire stroke range.
Regular replacement of seals using these kits helps restore optimal cylinder performance, prevents air leakage, and extends the service life of existing actuators, all while being more cost-effective than a full replacement. Please note that the seal kit does not include a grease pack, which must be ordered separately. The grease pack part number is GR-S-010 and contains 10 grams of grease.
Features:
The Complete Seal Kit is designed to provide a comprehensive solution for cylinder rebuilding. Each kit contains piston packing, rod packing, as well as gasket A and gasket B, ensuring a full and thorough rebuild of your cylinder components.
This seal kit supports a wide range of bore sizes, making it versatile for various applications. It is available for bore diameters including 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm, allowing users to select the perfect fit for their needs.
Constructed using high-quality NBR (nitrile rubber), the seals provide exceptional resistance to oil and wear. This ensures durability and reliability, contributing to extended service life and consistent performance under demanding conditions.
Specifically engineered to be compatible with the MGQ Series, these kits are ideal for use with MGQ compact guide rod cylinders that feature an integrated guide system. This compatibility guarantees seamless integration and optimal functionality.
By replacing worn or damaged seals, the kit effectively restores cylinder performance. It eliminates air leakage issues, bringing the cylinder back to its original force output and operational speed, thereby improving efficiency and reliability.
The kit is also suitable for cylinders that require non-rotating accuracy within a tight tolerance range of ±0.04° to ±0.08°. This ensures precise movement and positioning during cylinder operation, which is critical in many industrial applications.
Featuring a slide bearing type design, the seal kit offers superior lateral load resistance—more than twice that of traditional stopper cylinders. This enhances the durability and robustness of the cylinder under lateral stress conditions.
All models in this kit come equipped with built-in magnets, which facilitate auto switch position detection. This feature improves operational control and monitoring capabilities without additional modifications.
Choosing this seal kit is a cost-effective maintenance strategy. It significantly reduces expenses compared to purchasing a new cylinder, while also extending the overall service life of the actuator components.
The kit is suitable for use within an operating temperature range from -10°C to +60°C, and an operating pressure range of 0.1 to 1.0 MPa. These specifications make it adaptable for diverse working environments and conditions.
For inventory management convenience, the kit is organized by a single kit number per bore size, simplifying stocking and selection processes for maintenance teams.
Additionally, a grease pack (model GR-S-010, 10g) is available separately. This grease is recommended for proper lubrication during installation, ensuring the seals operate smoothly and last longer.
Technical Parameters:
| Series |
MGQ |
| Product Type |
Seal Kit / Repair Kit |
| Action Type |
Double Acting |
| Operating Temperature Range |
-10°C To +60°C |
| Kit Contents |
Piston Packing, Rod Packing, Gasket A, Gasket B |
| Proof Pressure |
1.5 MPa |
| Bore Sizes |
12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm |
| Seal Material |
NBR (Nitrile Rubber) |
Applications:
Maintenance and Repair of Compact Guide Cylinders in Various Applications
Conveyor Line Stoppers
We provide maintenance services for compact guide cylinders that function as stoppers and positioning devices along conveyor lines. Our expertise ensures the smooth and reliable operation of these essential components.
Lifters and Pushers
Seal replacement for cylinders used in lifting and pushing tasks is one of our specialties. Proper sealing is critical to maintaining the efficiency and safety of these applications.
Pick and Place Units
We handle the repair of guided cylinders that are integral to precision positioning systems in pick and place units, helping maintain accuracy and performance.
Factory Automation
Our maintenance services extend to guided cylinders used in automated production lines, ensuring minimal downtime and consistent functionality for factory automation systems.
Material Handling
We offer seal kits and maintenance solutions for cylinders employed in conveyors and material handling systems, enhancing their durability and operational lifespan.
Packaging Machinery
Cylinder maintenance for packaging and filling equipment is provided, helping to keep packaging machinery running smoothly and efficiently.
Electronic Component Manufacturing
Our repair services include cylinders used in precision assembly equipment within the electronic component manufacturing sector, supporting high-quality production standards.
General Industrial Pneumatics
For any industrial application requiring dependable sealing of compact guide cylinders, we deliver reliable solutions to meet diverse operational needs.
Customization:
Introducing the SMC Pulse Valve Diaphragm, model number MGQ12-PS, proudly made in China and certified with CE standards. This high-quality solenoid valve sealing diaphragm is part of the MGQ series, designed to ensure optimal performance and durability in various industrial applications.
Our pilot valve repair kit includes essential components such as piston packing, rod packing, gasket A, and gasket B, providing a comprehensive solution for maintaining and repairing your solenoid valves. Available in bore sizes ranging from 12mm to 63mm, this 3/8‑2 1/2 inch solenoid valve diaphragm kit is versatile and suitable for a wide range of valve sizes.
The seal material used is premium NBR (Nitrile Rubber), ensuring excellent resistance to wear and tear, enhancing the longevity of the seal kit. With a minimum order quantity of just 1 piece, this seal kit/repair kit is perfect for both small and large scale operations.
Packaging is done carefully in cartons to protect the product during transit. We offer flexible payment terms including T/T, Western Union, and Paypal, making the purchasing process convenient. Delivery time is prompt, typically within 1-7 work days after payment.
With a supply ability of 5000 pieces per month, we are well-equipped to meet your demand. Price is negotiable based on order quantity and customization needs. Choose SMC for reliable and efficient pulse valve diaphragms and pilot valve repair kits.
