CQMB40 PS Maintenance Seal Kit fits SMC CQMB40 flat actuator Oil dust resistant seals for long time running material handling automation equipment

Product Description:

These guide rod cylinder seal kits are precisely engineered replacement sets, specifically designed for the maintenance and refurbishment of CQMB series compact guided pneumatic cylinders. They are available for bore sizes ranging from 12mm to 63mm. Each kit includes all the essential sealing components necessary for a complete cylinder rebuild, such as the piston seal, rod seal, and tube gasket.

The seals are made from premium NBR (nitrile rubber), which provides excellent resistance to wear, oil, and abrasion, ensuring dependable performance in pneumatic applications. The CQMB series compact guide cylinders incorporate an integrated guide rod and plate design, delivering a high non-rotating accuracy of ±0.2° as well as a lateral load resistance that is four times greater than that of standard CQ2K cylinders. This makes them highly suitable for precision assembly and pick-and-place tasks.

Regular replacement of seals using these kits helps to restore the cylinder’s performance, prevents air leakage, and significantly extends the service life of existing actuators at a much lower cost compared to full replacement. Please note that the seal kit does not include a grease pack, which must be purchased separately. The grease pack part number is GR-S-010 and comes in a 10g size.

Features:

This comprehensive seal kit includes all the necessary components for a full cylinder rebuild: a piston seal, a rod seal, and a tube gasket. Each kit is designed to provide everything needed to restore your cylinder to optimal working condition.

The kit is available in a variety of bore sizes to fit different applications, including 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm. This broad range ensures compatibility with a multitude of cylinder sizes.

High-quality seals made from nitrile rubber (NBR) are included for their excellent resistance to oil and wear. This material choice ensures long-lasting durability and reliable performance under various operating conditions.

Specifically designed for the CQMB series of compact guide rod cylinders, which feature integrated guide rods, this seal kit ensures a perfect fit and seamless replacement process.

By replacing worn or damaged seals, the kit effectively eliminates air leakage, helping to recover the original force and speed of your cylinder. This maintenance step is crucial for maintaining optimal actuator functionality.

The seals are compatible with cylinders that maintain a ±0.2° non-rotating accuracy, providing precise operation. Additionally, they support cylinders that offer four times the lateral load resistance compared to the CQ2K series, ensuring enhanced durability.

Opting for this seal kit as a maintenance measure is a cost-effective alternative to purchasing a new cylinder. It helps extend the service life of your actuators while significantly reducing downtime and expenses.

The seals perform reliably within a temperature range of -10°C to +70°C, making them suitable for various industrial environments.

Each bore size is assigned a unique kit number, simplifying inventory management and ordering processes for maintenance teams.

For proper lubrication during installation, a separate grease pack (GR-S-010, 10g) is available, ensuring the seals are installed smoothly and perform optimally.

Technical Parameters:

Applications:

In the realm of pick and place units, maintaining guided cylinders is essential for ensuring precise positioning and smooth operation. Proper upkeep helps in extending the lifespan and accuracy of these critical components.

Factory automation heavily relies on the efficient repair and maintenance of guided cylinders within automated production lines. Timely servicing minimizes downtime and keeps the manufacturing process running seamlessly.

Material handling systems such as conveyors depend on cylinders with properly functioning seals. Replacing worn seals helps maintain the efficiency and safety of these handling systems.

High-force clamping and pressing operations require robust maintenance practices for the cylinders involved. Ensuring these cylinders are in optimal condition is vital for reliable performance during demanding tasks.

In packaging machinery, using specialized seal kits for cylinders employed in packaging and filling equipment enhances the durability and reliability of these machines.

The production of electronic components demands precise assembly equipment, where regular cylinder maintenance is crucial to maintain accuracy and consistency throughout the manufacturing process.

CNC machines, known for their high precision, require expert repair of guided cylinders used in their machine tools to sustain operational excellence and precision.

Across general industrial pneumatics, any application that requires dependable guided cylinder sealing benefits from diligent maintenance and seal replacement to ensure long-term reliability and performance.
