Replacement Service Kit CQMB50 PS for SMC CQMB series pneumatic cylinder Tough sealing components fix pressure drop save investment instead of buying brand new cylinder

Product Description:

These guide rod cylinder seal kits are precisely engineered replacement sets intended for the maintenance and complete overhaul of CQMB series compact guided pneumatic cylinders. They are available for bore sizes ranging from 12mm to 63mm. Each kit includes all the essential sealing components needed for a thorough cylinder rebuild, such as the piston seal, rod seal, and tube gasket.

The seals are crafted from premium quality NBR (nitrile rubber), which provides exceptional resistance to wear, oil, and abrasion. This ensures dependable performance in various pneumatic applications. The CQMB series compact guide cylinders incorporate an integrated guide rod and plate design, delivering high non-rotating accuracy of ±0.2° as well as lateral load resistance that is four times greater than that of standard CQ2K cylinders. These characteristics make the cylinders particularly suited for precision assembly and pick-and-place operations.

Using these seal kits for regular replacements helps restore the cylinder's performance, prevent air leakage, and significantly extend the service life of existing actuators. This maintenance approach is a cost-effective alternative compared to purchasing new cylinders. Please note that the seal kit does not come with a grease pack. The grease pack should be purchased separately, with the part number GR-S-010 (10g).

Features:

The Complete Seal Kit includes all necessary components for a thorough cylinder rebuild. Each kit comes with a piston seal, rod seal, and tube gasket, ensuring a comprehensive restoration of your cylinder’s functionality.

This seal kit is available in a wide range of bore sizes, including 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm. This versatility makes it suitable for various applications and cylinder models.

Manufactured using high-quality NBR (nitrile rubber) seals, the kit provides excellent resistance to oil and wear. These durable seals help extend the service life of your cylinders by maintaining optimal sealing performance.

Specifically designed for compatibility with CQMB series compact guide rod cylinders, the kit fits perfectly with models featuring built-in guide rods. This ensures seamless integration and reliable operation.

By replacing worn or damaged seals, the kit effectively eliminates air leakage, restoring the original force and speed of the cylinder. This maintenance step is crucial to maintaining peak cylinder performance.

The seal kit supports cylinders that offer a high degree of non-rotating accuracy, with tolerances of ±0.2°. This precision makes it ideal for applications requiring exact positioning and minimal rotational play.

Designed to handle high lateral loads, the kit is suitable for cylinders capable of withstanding lateral loads up to four times greater than the CQ2K series. This robustness ensures dependable performance under demanding conditions.

Opting for this seal kit is a cost-effective maintenance solution. It provides an affordable alternative to purchasing new cylinders while significantly extending the service life of your existing actuators.

The operating temperature range for the seals is between -10°C and +70°C, making them suitable for a variety of environments and working conditions.

Inventory management is simplified by having a single kit number assigned to each bore size, making it convenient to stock and reorder the appropriate seal kits as needed.

Additionally, a separate grease pack (GR-S-010, 10g) is available to ensure proper lubrication during the installation process, helping to further enhance seal performance and longevity.
